Desktop Metallographic Precision Cutting Machine
INQUIRYModel
TNC-D150A
- Product Feature
- Product Specification
Desktop Metallographic Precision Cutting Machine
This cutting machine can apply on the small and fragile product. It contain X direction fix size function, it's suitable for sample that need displacement accuracy, easy to use and can control the cutting speed and maintain in the certain speed. Focus on certain field such as: metal hardness stable heat treatment process, determine of surface coating size, ceramic material electrical parts observation and related skill development quality management etc.
| Item | Model / Specification Description | |
|---|---|---|
| TNC-D150A | ||
| Structure | desktop | |
| Transmission system | power | 100W(60/50Hz) |
| (RPM) | 0~3000RPM(50/60Hz) | |
| Cutting blade specifications | outer diameter | ∅150mm Flange size∅55mm |
| Inner diameter | Shaft diameter∅31.75(*∅25.4)mm | |
| cutting blade | Diamond Cut Disc/Alumina Grinding Wheel (Sold Separately) | |
| Sample holder | Fixture type | clip type |
| locking method | tool afterburner | |
| Left and right displacement | Up to 15mm left and right from the center | |
| maximum height | 30mm | |
| Control System | panel form | Key control panel LCD display |
| Function | Operation starts, operation stops | |
| Displacement to zero/RPM | ||
| Feeding device | Knife setting method | Visually |
| Manual feed | handle indirect | |
| cooling device | water tank capacity | 3L |
| weight | 25kg | |
| size | W320*D500*H360 | |
| using electric | AC220V/380V 50Hz/60Hz 3P | |
| Safety | The upper cover is not properly closed and cannot be started, and the upper cover is opened during operation and stops running | |
| Machine | size | W800*D900*H1300 |
| weight | 21kg | |
| Standard accessories | Cutting fluid*1, standard set of sample clips, toolbox (including tools)*1set | |
